Conformal Coated Inductors - Axial
ctparts.com
CTC1F Series
From .10 µH to 1,000 µH
Part
Number
CTC1F-R10_
CTC1F-R12_
CTC1F-R15_
CTC1F-R18_
CTC1F-R22_
CTC1F-R27_
CTC1F-R33_
CTC1F-R39_
CTC1F-R47_
CTC1F-R56_
CTC1F-R68_
CTC1F-R82_
CTC1F-1R0_
CTC1F-1R2_
CTC1F-1R5_
CTC1F-1R8_
CTC1F-2R2_
CTC1F-2R7_
CTC1F-3R3_
CTC1F-3R9_
CTC1F-4R7_
CTC1F-5R6_
CTC1F-6R8_
CTC1F-8R2_
CTC1F-100_
CTC1F-120_
CTC1F-150_
CTC1F-180_
CTC1F-220_
CTC1F-270_
CTC1F-330_
CTC1F-390_
CTC1F-470_
CTC1F-560_
CTC1F-680_
CTC1F-820_
CTC1F-101_
CTC1F-121_
CTC1F-151_
CTC1F-181_
CTC1F-221_
CTC1F-271_
CTC1F-331_
CTC1F-391_
CTC1F-471_
CTC1F-561_
CTC1F-681_
CTC1F-821_
CTC1F-102_
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CTC1F-R10_
J = ±5%, K = ±10%, M = ±20%
L Test
Freq.
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
Q
Factor
Min.
40
40
38
38
33
33
30
30
30
30
28
28
25
25
28
30
30
37
45
45
45
50
50
55
55
45
45
50
50
50
45
45
45
45
50
50
50
30
30
30
30
30
30
30
30
30
30
30
30
Q Test
Freq.
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
SRF
Min.
(MHz)
680
640
600
550
510
430
410
365
330
300
275
250
230
150
140
125
115
100
90
80
75
65
60
55
50
40
35
30
25
20
24
22
20
18
15
14
13
12
11
10
9.0
8.0
7.0
6.5
6.0
5.0
4.2
3.8
3.4
DCR
Max.
Ω
(Ω)
.08
.09
.10
.12
.14
.16
.22
.30
.35
.50
.60
.85
1.0
.18
.22
.30
.40
.55
.90
1.0
1.2
1.8
2.0
2.7
3.3
2.7
2.8
3.1
3.3
3.5
3.4
3.6
4.5
5.7
6.7
7.3
8.0
13
15
17
21
25
28
35
42
46
60
65
72
Rated
DC
(mA)
1380
1300
1230
1120
1040
975
830
710
660
550
500
420
390
620
560
480
415
355
285
263
239
195
185
160
144
144
144
144
144
140
130
125
110
100
92
88
84
68
61
57
52
47
45
40
38
35
30
28
28
Inductance
(µH)
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Compliant
RoHS
CHARACTERISTICS
Description:
Axial leaded conformal coated inductor
Applications:
Used in less harsh environments. Ideal for less
critical RFL/EMI applications
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±5%, ±10%, ±20%
Material:
Epoxy resin over coil. Magnetic core (ferrite or iron)
except for values .10 µH to 1.0 µH (phenolic)
Packaging:
Bulk pack, 1,000 parts per bag,
Tape & Reel, 5,000 parts per reel
Marking:
Parts are EIA color banded which indicates inductance
value and tolerance
Testing:
Inductance and Q are tested on an HP4285A at
specified frequency
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
6.22
0.245
2.3 ± 0.25
0.09 ± 0.01
B
C
Nom.
26.7
1.05
24 AWG
Nom.
0.5110
0.02010
12.12.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
