LS404MD datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> LS404MD

LS404MD: DescriptionQUAD OP-AMP, 2500uV OFFSET-MAX, 3MHz BAND WIDTH, PDSO14, MICRO, PLASTIC, SO-14; CategoryAnalog mixed-signal IC Amplifier circuit; File Size255KB，11 Pages; ManufacturerSTMicroelectronics; Websitehttp://www.st.com/; Environmental Compliance

Download Datasheet Parametric View All

LS404MD Overview

QUAD OP-AMP, 2500uV OFFSET-MAX, 3MHz BAND WIDTH, PDSO14, MICRO, PLASTIC, SO-14

LS404MD Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	STMicroelectronics
Parts packaging code	SOIC
package instruction	SOP, SOP14,.25
Contacts	14
Reach Compliance Code	compliant
ECCN code	EAR99
Amplifier type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Maximum average bias current (IIB)	0.2 µA
Maximum bias current (IIB) at 25C	0.2 µA
Nominal Common Mode Rejection Ratio	94 dB
frequency compensation	YES
Maximum input offset voltage	2500 µV
JESD-30 code	R-PDSO-G14
JESD-609 code	e4
length	8.65 mm
low-dissonance	NO
Negative supply voltage upper limit	-18 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	4
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP14,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	+-15 V
Certification status	Not Qualified
Maximum seat height	1.75 mm
minimum slew rate	0.8 V/us
Nominal slew rate	1.5 V/us
Maximum slew rate	2 mA
Supply voltage upper limit	18 V
Nominal supply voltage (Vsup)	15 V
surface mount	YES
technology	BIPOLAR
Temperature level	MILITARY
Terminal surface	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	3000 kHz
Minimum voltage gain	31600
width	3.9 mm

Preview

Download Datasheet

View All

LS404

HIGH PERFORMANCE

QUAD OPERATIONAL AMPLIFIER

SINGLE OR SPLIT SUPPLY OPERATION

LOW POWER CONSUMPTION

SHORT CIRCUIT PROTECTION

LOW DISTORTION, LOW NOISE

HIGH GAIN-BANDWIDTH PRODUCT

HIGH CHANNEL SEPARATION

DIP14

(Plastic Package)

DESCRIPTION

The LS404 is a high performance quad operation-

al amplifier with frequency and phase compensa-

tion built into the chip. The internal phase compen-

sation allows stable operation as voltage follower

in spite of its high Gain-Bandwidth Product.

The circuit presents very stable electrical charac-

teristics over the entire supply voltage range, and

is particularly intended for professional and tele-

com applications (active filter, etc).

The patented input stage circuit allows small input

signal swings below the negative supply voltage

and prevents phase inversion when the inputs are

over drivers.

ORDER CODE

Package

Part Number Temperature Range

LS404C

0°C, +70°C

LS404I

-40°C, +105°C

LS404M

-55°C, +125°C

Example :

LS204CN

•

SO14

(Plastic Micropackage)

PIN CONNECTIONS

(top view)

Output 1 1

Inverting Input 1 2

Non-inverting Input 1

Non-inverting Input 2

Inverting Input 2

Output 2

14 Output 4

13 Inverting Input 4

12 Non-inverting Input 4

11 V

10 Non-inverting Input 3

Inverting Input 3

Output 3

N =

Dual in Line Package (DIP)

D =

Small Outline Package (SO) - also available in Tape & Reel (DT)

November 2001

1/11
