ALUMINUM ELECTROLYTIC CAPACITORS
HE
Miniature Sized, Low Impedance,High Reliability
series
Approved by Reliability Center for Electronic
Component, Japan-Certification No. RCJ-03-23C
Low impedance and high reliability withstanding 4000hours to 10000hours.
HD
Long Life
HE
Specifications
ltem
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Performance Characteristics
—40 ~ +105˚C
6.3 ~ 100V
6.8 ~ 18000µF
±20% at 120Hz, 20˚C
After 2 minutes' application of rated voltage, leakage current is not more than 0.01CV or 3 (µA), whichever is greater.
Rated voltage (V)
6.3
0.22
10
0.19
16
0.16
25
0.14
35
0.12
50
0.10
63
0.09
100
0.08
120Hz
20˚C
tan
δ
tan
δ
(MAX.)
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
Rated voltage (V)
Stability at Low Temperature
6.3
4
8
10
3
6
16
2
4
25
2
3
35
2
3
50
2
3
63
2
3
100
2
3
120Hz
Impedance ratio
ZT/Z20(MAX.)
Z—20˚C / Z+20˚C
Z—40˚C / Z+20˚C
After an application of D.C. bias voltage plus the rated ripple current for stated in the below at 105˚C the peak voltage shall not
exceed the rated D.C. voltage, capacitors shall meet the following requirements.
Case size
Endurance
φD
< 6.3
=
4000hours
5000hours
φD=8
, 10
6000hours
7000hours
φD
> 12.5
=
8000hours
10000hours
Rated voltage
(V)
6.3 ~ 10WV
16 ~ 100WV
Capacitance change
tan
δ
Leakage current
Shelf Life
Marking
Within ±25% of initial value
200% or less of initial specified value
lnitial specified value or less
After leaving capacitors under no load at 105˚C for 1000 hours, they meet the specified value for endurance characteristics
listed above.
Printed with white color letter on black sleeve.
Radial Lead Type
Sleeve(P.E.T.)
Type numbering system (Example : 10V 1000µF)
φ
d
1
2
3
4
5
6
7
8
9
10 11
12
U HE 1 A 1 0 2 M P T
φD
+
0.5 MAX
Size code
P±
0.5
Configuration
Capacitance tolerance (±20%)
Rated Capacitance(1000µF)
φ
D
5
6.3
8
•
10
12.5~18
Code
DT
ET
PT
HT
Pressure
relief vent
(
φ
D
6.3)
L
+
MAX
15
MIN
4
MIN
Rated voltage (10V)
(mm)
Series name
Type
(L < 20)1.5
(L 20)2.0
φD
P
φd
5
2.0
0.5
6.3
2.5
0.5
8
3.5
0.6
10
5.0
0.6
12.5
5.0
0.6
16
7.5
0.8
18
7.5
0.8
In case L>25 for the
φ12.5
dia. unit, lead dia.
φd=0.8mm
Please refer to page 18, 19, 20 about the formed or taped product spec.
Please refer to page 3 for the minimum order quantity.
Dimension table in next pages.
