HIGH-PERFORMANCE COMMUNICATION VARIABLE
GAIN-CONTROL AMPLIFIER MODULE
HVGC SERIES
HVGC series amplifiers provide continuous gain adjust with the application of external control voltage. These
amplifiers are used in IF transmit/receive chains to enable the user to adjust the gain as necessary to compensate
for the insertion loss of the integrated modules. Optionally, the gain variation versus control voltage can be lin-
earized (dB/volt) through the entire dynamic range for customized applications.
FEATURES
• Excellent passband gain flatness
• Wide input dynamic ranges available
• Low noise figure
MODEL
NUMBER*
CENTER FREQUENCY
(MHz)
FREQUENCY SPAN
(MHz)
30 MHz IF
HVGC-40-30-20-I/O
HVGC-50-30-20-I/O
HVGC-60-30-20-I/O
HVGC-70-30-20-I/O
30
30
30
30
20
20
20
20
70 MHz IF
HVGC-40-70-40-I/O
HVGC-50-70-40-I/O
HVGC-60-70-40-I/O
HVGC-70-70-40-I/O
70
70
70
70
40
40
40
40
140 MHz IF
HVGC-40-140-40-I/O
HVGC-50-140-40-I/O
HVGC-60-140-40-I/O
HVGC-40-140-80-I/O
HVGC-50-140-80-I/O
HVGC-60-140-80-I/O
HVGC-70-140-80-I/O
140
140
140
140
140
140
140
40
40
40
80
80
80
80
160 MHz IF
HVGC-40-160-40-I/O
HVGC-50-160-80-I/O
HVGC-70-160-80-I/O
160
160
160
40
80
80
200 MHz IF
HVGC-40-200-40-I/O
HVGC-50-200-80-I/O
HVGC-70-200-80-I/O
200
200
200
40
80
80
40
50
70
0.25
0.5
0.6
40
50
70
0.25
0.5
0.6
40
50
60
40
50
60
70
0.25
0.25
0.25
0.5
0.5
0.5
0.6
40
50
60
70
0.25
0.2
0.2
0.3
40
50
60
70
0.15
0.15
0.2
0.25
DYNAMIC RANGE
(dB)
GAIN FLATNESS
(dB)
* I = Input impedance; O = Output impedance.
For impedance of 75 ohms, I or O = 7; for impedance of 50 ohms, I or O = 5.
9
COMMON ELECTRICAL SPECIFICATIONS
Input/output impedance .......................................
Input return loss...................................................
Noise figure..........................................................
Output power .......................................................
Output return loss ................................................
Gain control .........................................................
50 or 75 ohms
> 18 dB
< 8 dB
0 dBm
> 18 dB
External voltage or multiturn potentiometer
PRIMARY POWER REQUIREMENTS
Current/voltage .................................................... 150 mA @ +15 volts
40 mA @ -15 volts
MECHANICAL SPECIFICATIONS
PHYSICAL
Dimensions .......................................................... 2.1” x 2.1” x .75”
CONNECTORS
Input/output..........................................................
DC power.............................................................
Gain control voltage.............................................
Housing ground ...................................................
SMA female
Feedthru terminal
Feedthru terminal
2-56 terminal
OPTIONS
HVG-1
HVG-2
HVG-3
HVG-4
Output test monitor port (output impedance is the same as the main output).
Other center frequencies (customer to specify).
Wider frequency span (customer to specify).
Other dynamic ranges (customer to specify).
