Loli brushless ESC 2020 version PN double layer v1

Overview

The original post is https://www.moz8.com/thread-182113-1-1.html

My homework submission post is at https://www.moz8.com/thread-182374-1-1.html

The MOS tube chosen is AON6407/RU3090M, which is about 20~30A. The usable range of 2S~4S can be added with a heat sink.

I don’t have a 5V BEC output because I think distribution boards are so easy to buy now…………

The black one in the picture is this board, and the green one is for size comparison.
