ReleaseV1-Male key line separated version charging module V2

Overview

Verified. Be careful not to reverse the positive and negative poles of the battery! Connect the anti-burn TP4056 chip!

The module uses the TP4056 chip as the core, which can realize constant current/constant voltage charging of a complete single-cell lithium-ion battery. The charging current I = 1200/R1 = 1A (when the input power is sufficient). The module is equipped with a charging indicator light and a standby indicator light. When charging, the charging indicator LED1 (red) is on; when fully charged, LED1 is off and the standby indicator LED2 (green) is on; when no battery is connected, LED2 is on and LED1 is 1 Flashes at a frequency of ~4S. The module has an under-voltage lockout function and an automatic recharge function. When the power supply VCC is input, the data download address is: https://www.jixin.pro/product/1917.html
