LUXEON Q
Industry Standard 3535 Footprint Delivering
High Efficacy at High Drive Current
Introduction
LUXEON
®
Q delivers superior performance in a high power emitter that serves as a direct drop-in
replacement for products that use the standard 3535 surface mount package. LUXEON Q is the first
high-power LED based on LUXEON Flip Chip die, Philips Lumileds high performance Chip Scale Package
(CSP) device architecture.
The LUXEON Q takes advantage of a fully developed ecosystem for 3535 components, including
optics, to speed the time-to-market for indoor and outdoor luminaires.
Features
• Industry
standard 3535 package
• LUXEON
Flip Chip, high performance
Chip Scale Package (CSP) LED
• High
efficacy at high drive current
• Freedom from Binning
- 3 & 5 SDCM
• Hot
tested at T
j
= 85°C
• UL-recognized
component [E352519]
with level 4 enclosure consideration
Benefits
• Faster
time to market
• Industry
leading performance
• High
lumen and lm/$ at high lm/W
• Delivers
color consistency
Key Applications
• Downlights
• High
bay & Low bay
• Lamps
• Outdoor
- Outdoor Area
- Roadway & Parking
- Tunnel
• Specialty
LUXEON Q Datasheet DS118 ©2014 Philips Lumileds Lighting Company.
Table of Contents
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Average Lumen Maintenance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Selection & Optical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
JEDEC Moisture Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Reflow Soldering Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Solder Pad Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Relative Spectral Distribution vs . Wavelength Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Typical Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Typical Forward Current Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Typical Radiation Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Emitter Pocket Tape Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Emitter Reel Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Product Binning and Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Luminous Flux and Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
LUXEON Q 3-step and 5-step MacAdam Ellipse Color Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
LUXEON Q Datasheet DS118 20140109 ©2014 Philips Lumileds Lighting Company.
i
General Information
Product Nomenclature
LUXEON Q emitters are specified and binned “hot” under conditions comparable to those found in “real-world” lighting
products. The test conditions for LUXEON Q are 350 mA DC with junction temperature at 85°C.
The part number designation is explained as follows:
L1Q0-xxyy00000zzz0
Where:
xx
yy
zzz
—
—
—
designates nominal ANSI CCT (27 for 2700K, 30 for 3000K)
designates minimum CRI performance (70 for 70 CRI, 80 for 80 CRI)
designates minimum flux performance at standard binning current and temperature (090 for 90lm,
110 for 110lm, etc)
Therefore, 80 CRI products tested and binned at 3000K with a 100lm minimum flux at binning current and temperature will
have the part numbering scheme:
L1Q0-3080000001000
Therefore, 70 CRI products tested and binned at 5700K with a 120lm minimum flux at binning current and temperature will
have the following part numbering scheme:
L1Q0-5770000001200
Average Lumen Maintenance Characteristics
LUXEON Q products are tested in compliance with LM-80. Please visit
www.philipslumileds.com/support/documentation/
lumen-maintenance
or contact your local Philips Lumileds Technical Solutions Manager for TM-21 extrapolations or other
support.
Environmental Compliance
Philips Lumileds is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON Q
is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment, namely the
RoHS and REACH directives. Philips Lumileds will not intentionally add the following restricted material to the LUXEON Q:
lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated diphenyl ethers (PBDE).
LUXEON Q Datasheet DS118 20140109 ©2014 Philips Lumileds Lighting Company.
2
Product Selection & Optical Characteristics
Product Selection Guide for LUXEON Q Emitters
Junction Temperature = 85°C
Table 1.
Typical Performance Characteristics at 350 mA, 700 mA, and 1000 mA for LUXEON Q, Junction Temperature = 85°C
Part Number
L1Q0-278000000zzz0
L1Q0-308000000zzz0
L1Q0-358000000zzz0
L1Q0-407000000zzz0
L1Q0-577000000zzz0
Notes for Table 1:
1. Philips Lumileds maintains a tolerance of ± 6.5% on luminous flux and ± 2 on CRI measurements.
Nominal
ANSI CCT
2700K
3000K
3500K
4000K
5700K
CRI
700 mA
80 min
80 min
80 min
70 min
70 min
Luminous Flux (lm) Min
350 mA
80
90
90
110
110
Typical Luminous Flux (lm)
100
102
106
123
127
177
183
189
220
229
231
240
251
293
305
Typical Forward Voltage (V
f
)
2.81
2.81
2.81
2.81
2.81
2.93
2.93
2.93
2.93
2.93
2.99
2.99
2.99
2.99
2.99
Typical Efficacy (lm/W)
102
104
108
125
129
86
89
92
107
112
77
80
84
98
102
350 mA 700 mA 1000 mA 350 mA 700 mA 1000 mA 350 mA 700 mA 1000 mA
Optical Characteristics
LUXEON Q at Test Current
[1]
, Junction Temperature = 85°C
Table 2.
Nominal
ANSI CCT
2700K
3000K
3500K
4000K
5700K
Notes for Table 2:
1. Test current is 350 mA D.C. for all L1Q0-xxyy00000zzz0 emitters.
2. Total angle at which 90% of total luminous flux is captured.
3. Viewing angle is the off axis angle from lamp centerline where the luminous intensity is ½ of the peak value.
Part
Number
L1Q0-278000000zzz0
L1Q0-308000000zzz0
L1Q0-358000000zzz0
L1Q0-407000000zzz0
L1Q0-577000000zzz0
Typical
Color Temperature
CCT
2725K
3045K
3465K
3985K
5665K
Typical Total Included Angle
[2]
(degrees)
u
0 .90V
160
160
160
160
160
Typical Viewing Angle
[3]
(degrees)
2u 1/2
135
135
135
135
135
LUXEON Q Datasheet DS118 20140109 ©2014 Philips Lumileds Lighting Company.
3
Electrical Characteristics
Electrical Characteristics at test current for LUXEON Q
Junction Temperature = 85°C
Table 3.
Forward Voltage V
f
(V)
[1]
Nominal
ANSI CCT
Minimum
2.75
2.75
2.75
2.75
2.75
Maximum
3.25
3.25
3.25
3.25
3.25
Typical Temperature Coefficient
Typical Thermal Resistance
of Forward Voltage
[2]
(mV/°C) Junction to Thermal Pad (°C/W)
DV
F
/
DT
J
Ru
J-C
-1.6
-1.6
-1.6
-1.6
-1.6
7
7
7
7
7
2700K
3000K
3500K
4000K
5700K
Notes for Table 3:
1. Philips Lumileds maintains a tolerance of ± 0.06V on forward voltage measurements.
2. Measured between T
J
= 25°C and T
J
= 110°C at I
f
= 350 mA.
Absolute Maximum Ratings
Table 4.
Parameter
DC Forward Current (mA)
[1] [2]
Peak Pulsed Forward Current (mA)
[1] [3]
ESD Sensitivity
LED Junction Temperature
[1]
Operating Case Temperature at 700 mA
Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
Reverse Voltage (Vr)
[4] [5]
Notes for Table 4:
1. Proper current derating must be observed to maintain junction temperature below the maximum. For additional information on thermal measurement guidelines please
refer to Application Brief AB118 (not available yet).
2. Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple”, with frequencies
≥
100 Hz and amplitude
≤
150 mA are acceptable, assuming the average current throughout each cycle does not exceed 1050 mA.
3. Pulsed operation with a peak drive current of 1200 mA is acceptable if the pulse on-time is
≤
5 ms per cycle and the duty cycle is
≤
50%
4. Transient reverse voltages and surge currents due to electrical switching or supply interruptions are acceptable if these events do not last for more than 10ms, the
amplitude of the reverse voltage does not exceed 5V and the reverse current is less than 200μA.
5. Max 5V reverse for up to 10s is an acceptable beginning of life, one time test condition.
LUXEON Q
1050
1200
< 8000V Human Body Model (HBM) Class 3A JESD22-A114-E
135°C
-40°C - 135°C
-40°C - 135°C
JEDEC 020c 260°C
3
LUXEON Q LEDs are not designed to be driven in reverse bias
LUXEON Q Datasheet DS118 20140109 ©2014 Philips Lumileds Lighting Company.
4
