【Solicitation Order】ESP8266 Weather Clock

Introduction: Based on ESP8266 weather clock, displays local local location, time and local temperature

### Project Introduction

Background: Why do you want to make such a small thing?
I also saw other people doing it. I saw many such open source projects on the Lichuang open source platform and Bilibili, so I simply made such a gadget, the Astronaut Weather Clock.

- - -

### Project function introduction An

introduction and brief introduction to the relevant functions of the project, such as:

* Use 1.54-inch, Zhongjingyuan LCD screen
* PCB and schematic diagram are simply designed by myself. The circuit is very simple.
* Use TYPE-C interface for power supply and program update.
* The 1.54 LCD also has pin header terminals, and the upper and lower PCBs are connected by copper pillars.
* Disclaimer: The program was not written by me. It has been verified that the programs of two open source protocols can successfully light up the display.
* The astronaut with a white background belongs to the UP owner of station B. His open source program is in the attachment.

- -

-Design process:

* [x] Schematic design
* [x] PCB diagram design
* [x] PCB proofing
* [x] Welding test
* [x] Functional test
* [x] Program test

- - -

### The circuit explanation

circuit is relatively simple, no introduction is required

### Software```

C
const char ssid[] = ""; //Just change these two WIFI names
const char pass[] = ""; //WIFI password
```

- - -

### Picture

![image.png] PCB soldering diagram
![image.png] ![image.png]
- - -

###

- - -




- - -
